Kategori | : | V-SOL |
Promo | ||
Kode | : | V1601E04-DP |
Harga | : | Rp 5.100.000,00 |
V1601E04-DP vsol provides 4GE(copper) and 4*SFP/SFP+ slots independent interface for uplink, and 4*EPON OLT portsfor downlink. It can support overall 256 ONU's with 64 ONU's per PON port.
4*EPON, 4*RJ45+4*SFP/(SFP+)
*Sudah termasuk 4x SFP 9dBm
Specification
Model | V1601E04-DP |
Uplink Port | QTY : 8 |
RJ45(1G) : 4 | |
SFP(1G)/SFP+(10G) : 4 | |
EPON Port | QTY : 4 |
Physical Interface : SFP Slots | |
Supported PON module level : PX20, PX20+, PX20++, PX20+++ | |
Max splitting ratio : 1:64 | |
Management Port | 1*10/100 BASE-T out-band port, 1*CONSOLE port, 1*USB port |
Backplane Bandwidth (Gbps) | 128 |
Port Forwarding Rate(Mpps) | 71.424 |
PON Port Specification | Transmission Distance : 20KM |
EPON port speed”Symmetrical 1.25Gbps | |
Wavelength TX 1490nm RX 1310nm | |
Connector : SC/UPC | |
Fiber Type : 9/125μm SMF | |
Power supply | AC : Working Voltage Range: 100~240V, Rated Voltage: 110V/220V DC : Working Voltage Range: -36~-75V, Rated Voltage: -48V/-60V |
Management Mode | SNMP/Telnet/CLI/WEB/SSH v2 |
Working temperature | -20 ~ +60 C |
Storage temperature | -40 ~ +70 C |
Relative Humidity | 5 ~ 95% (Non-condensing) |
Dimension (L*W*H) | 442 x 200 x 43.6 mm |
Seluruh harga yang tercantum di atas belum termasuk PPN 11% dan biaya pengiriman.
Jika Anda membutuhkan faktur pajak untuk transaksi ini, pastikanlah bahwa Anda telah menginformasikan Nama Perusahaan dan NPWP dengan benar kepada kami sebelum melakukan order.
