| Kategori | : | MARUSON |
| Kode | : | SS2-HV2024M |
| Harga | : | |
| 1 - 4 | : | Rp 4.815.000,00 |
| 5 - ... | : | Rp 4.700.000,00 |
SS2-HV2024M adalah produk smart solar inverter yang cocok digunakan pada small office home office. Produk Inverter ini memiliki efisiensi yang cukup tinggi dan memiliki kapasitas 2000VA/2000Watt. Dilengkapi dengan solar charger 40A bertype MPPT.
*tidak termasuk battery
**Gunakan battery yang dirancang untuk SHS (Solar Home System) / Deep-cycle VRLA
| MODEL | SS2-HV2024M |
| Capacity | 2000 VA / 2000 Watt |
| INPUT | |
| Voltage | 230 VAC |
| Voltage Range Selectable | 170 ~ 280 VAC (for computers) |
| 90 ~ 280 VAC (for home appliances) | |
| Freq | 50 / 60 Hz (auto sensing) |
| OUTPUT | |
| AC Voltage Regulation (Battery Mode) | 230 VAC +/- 5% |
| Surge Power | 4000 VA |
| Efficiency (Peak) | 90 ~ 93% |
| Transfer Time | 10ms (for computers); 20ms (for home appliances) |
| Waveform | Pure sine wave |
| BATTERY | (Not Included) |
| Battery Voltage | 24 VDC |
| Floating Charge Voltage | 27 VDC |
| Overcharge Protection | 31 VDC |
| SOLAR CHARGER & AC CHARGER | |
| Solar Charger Type | MPPT |
| Max PV Array Open Circuit Voltage | 102 VDC |
| Max PV Array Power | 1000 W |
| MPP Range @ Operating Voltage | 30 ~ 80 VDC |
| Max Solar Charging Current | 40 A |
| Max AC Charging Current | 25 A |
| Combined AC & Solar Max Charging Current | 60 A |
| MANAGEMENT | |
| Interface | USB / RS-232 |
| Monitoring Software | |
| PROTECTION | |
| Full Protection | Overload and short circuit protection |
| INDICATOR | |
| Display | LCD |
| Alarm | Battery mode, Low battery, Overload, Fault |
| PHYSICAL | |
| Dimension (DxWxH) mm | 88 x 225 x 320 |
| Net Weight kg | 5 |
Manual : SS2-HV2024M.pdf
Seluruh harga yang tercantum di atas belum termasuk PPN 11% dan biaya pengiriman.
Jika Anda membutuhkan faktur pajak untuk transaksi ini, pastikanlah bahwa Anda telah menginformasikan Nama Perusahaan dan NPWP dengan benar kepada kami sebelum melakukan order.
